Description of center’s facilities and equipment

The research activity of the laboratory is focused in two main directions – creation of unique platforms for validation and certification of industrial solutions and components in railway control systems (ERTMS), incl. European Vital Computer (EVC) and Balise Transmission Module (BTM) test and analysis platforms: European Vital Computer (EVC) high-response on-board computer testing as required by Subset-26, Subset-076 and Subset-094; analysis of the compatibility of a train with the railway line, to provide an opportunity for early detection of problems in the validation of the train/railway line compatibility on the basis of design data, operational and technical rules, etc; testing of Eurobalises and BTM (Balise Transmission Module), according to Subset-036 and Subset-085; providing software and hardware tools for signal quality analysis from the balises; services and test capabilities for upgrading the road infrastructure to standards with newer versions (baselines). The research activities of the laboratory are focused on two main areas: creating platforms for next-generation communications analysis, including 5G and those in ISM frequency bands for LoRaWAN, IoT and M2M applications: the development of specific SW and HW platforms for simulating and analyzing the performance of next-generation telecommunication networks; RF data processing and communication spectrum occupancy analysis; new radio access technologies; IoT and M2M communications.

Temperature test chamber WeissTechnik 240/70 – temperature range -70 o C to +180 o C Signal generators – 3 pieces – Keysight 33522B – 2 channels, range 0 ÷ 30MHz Network analyzer (VNA) – 1 piece – Rohde Schwarz ZVL3 Network analyzer, range 9kHZ – 3 GHZ Spectrum analyzer – 1 piece – Tektronix RSA5103B, range 1 HZ – 3 GHZ Oscilloscope – 1 piece – Keysight DSOX3024A, bandwidth: 200 Hz USB power sensors – 3 pieces – Mini-Circuits PWR-SEN-4GHS, 9 kHz – 4000 kHz, -30 ÷ +20 dBm; Amplifiers – 2 pieces – Amplifier Research AR-150A100B-20dBm 150W and Multitel 30W Programmable DC power supply – 1 piece – Sorensen DLM 600 Antennas (reference loops) – 27 MHz and 4,234 MHz Automatic positioning tool – a European Vital Computers (EVC) test robot that allows positioning of an antenna, device, etc. in a 3D space measuring 6000x2000x800 mm with 0.1 mm accuracy Additional equipment for signal measurement – balancing modules, low-pass filters, power dividers, couplers, attenuators, cables, loads, etc. Field strength analyzers – 2 instruments – NARDA SRM-3000 selective radiation meter with isotropic and uniaxial probes, 100 kHz ÷ 3 GHz and NARDA NBM-550 broadband field meter, 100 kHz ÷ 6 GHz Additional equipment to simulate environmental conditions – metal objects, metal rails Software Defined Radio – 9 devices – 3x USRP B210 , 1x LimeSDR 5x ADALM-PLUTO 5G testbed, which is a private mobile network implemented using open-source platforms and widely used hardware
